Cisco C9300L-24UXG-4X-A Switch – High-Performance Network Solution

Model: C9300L-24UXG-4X-A – Cisco Catalyst 9300 Switches
Detail: Catalyst 9300L 24p, 8mGig, Network Advantage ,4x10G Uplink

Description of Cisco C9300L-24UXG-4X-A

The Cisco Catalyst 9300 Series switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry’s most widely deployed switching platform.

Categories: ,

Fast Shipping

Carrier information

20k products

Payment methods

24/7 Support

Unlimited help desk

Quick Spaces of Cisco C9300L-24UXG-4X-A

Table 1 shows the Quick Specs Cisco C9300L-24UXG-4X-A .

Product Code C9300L-24UXG-4X-A
Product Description Catalyst 9300 24-port fixed uplinks UPoE, 8xmGig, 4X10G uplinks, Network Advantage
Total 10/100/1000,Multigigabit copper or SFP Fiber 24 UPoE 8xmGig
Uplink Configuration 4x 10G fixed uplinks
Default AC power supply 1100W AC
Available PoE power 880W
Switching capacity 272 Gbps
Switching capacity with stacking 592 Gbps
Forwarding rate 202.38 Mpps
Forwarding rate with stacking 440.47 Mpps

C9300L-24UXG-4X-A Specification

Product Description Catalyst 9300 24-port fixed uplinks UPoE, 8xmGig, 4X10G uplinks, Network Advantage
FRU Power Supply Yes
FRU Fans Yes
Modular Uplinks No
Stacking Bandwidth Support 320 Gbps
Cisco StackPower No
Catalyst 9800 Embedded WLC Yes (50 APs)
SD-Access Support Yes (256 Virtual Networks)
Total 10/100/1000,Multigigabit copper or SFP Fiber 24 UPoE 8xmGig
Uplink Configuration 4x 10G fixed uplinks
Default AC power supply 1100W AC
Available PoE power 880W
Total number of MAC addresses 32,000
Total number of IPv4 routes (ARP plus learned routes) 32,000 (24,000 direct routes and 8000 indirect routes)
IPv6 routing entries 16,000
Multicast routing scale 8,000
QoS scale entries 5,120
ACL scale entries 5,120
Packet buffer per SKU 16 MB buffer for 24 and 48 port Gigabit Ethernet models
FNF entries 64,000 flow on 24- and 48-port Gigabit Ethernet models
DRAM 8 GB
Flash 16 GB
VLAN IDs 4094
Total Switched Virtual Interfaces (SVIs) 1000
Jumbo frames 9198 bytes
Total routed ports per Catalyst 9300 Series stack 416
Switching capacity 272 Gbps
Switching capacity with stacking 592 Gbps
Forwarding rate 202.38 Mpps
Forwarding rate with stacking 440.47 Mpps
Dimensions (H x W x D) Cms Chassis only 4.4 x 44.5 x 40.9
W/ Default Power Supply 4.4 x 44.5 x 48.8
W/ 1100W Power Supply 4.4 x 44.5 x 48.8
Mean Time Between Failures–MTBF (hours) 332,640
Acoustic noise

Measured per ISO 7779 and declared per ISO 9296

Bystander positions operating to an ambient temperature of 25°C



With AC power supply (with 24 PoE+ ports loaded for C9300 SKUs)

• LpA: 45dB typical, 48 dB max

• LwA: 5.6B typical, 5.9B max

With AC power supply (with half the number of PoE+ ports loaded for C9300L SKUs)

• LpA: 44dB typical, 47 dB max

• LwA: 5.5B typical, 5.8B max

Typical: Noise emission for a typical configuration

Maximum: Statistical maximum to account for variation in p

Connectors and cabling • 1000BASE-T ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling

• Multigigabit-T ports: RJ-45 connectors, 4-pair Cat 5E, Cat 6, Cat 6A UTP cabling

• 1000BASE-T SFP-based ports: RJ-45 connectors, 4-pair Cat 5E UTP cabling

• SFP transceivers: LC fiber connectors (single-mode or multimode fiber)

• SFP+ transceivers: LC fiber connectors (single-mode or multimode fiber)

• QSFP+ transceivers: MPO and LC fiber connectors (single-mode or multimode fiber)

• QSFP+ connector

• SFP+ connector

• Cisco StackWise stacking ports: copper-based Cisco StackWise cabling

• Cisco StackPower: Cisco proprietary power stacking cables

• Ethernet management port: RJ-45 connectors, 4-pair Cat 5 UTP cabling

• Management console port: RJ-45-to-DB9 cable for PC connections

Power connectors • Customers can provide power to a switch by using the internal power at the back of the switch

• Internal power supply connector: The internal power supply is an auto-ranging unit. It supports input

voltages between 100 (115 for 1100WAC) and 240 VAC. Use the supplied AC power cord to

connect the AC power connector to an AC power outlet

Safety certifications • UL 60950-1

• CAN/CSA-C222.2 No. 60950-1

• EN 60950-1

• IEC 60950-1

• AS/NZS 60950.1

• IEEE 802.3

Electromagnetic emissions certifications



• 47 CFR Part 15

• CISPR22 Class A

• EN 300 386 V1.6.1

• EN 55022 Class A

• EN 55032 Class A

• CISPR 32 Class A

• EN61000-3-2

• EN61000-3-3

• ICES-003 Class A

• TCVN 7189 Class A

• V-3 Class A

• CISPR24

• EN 300 386

• EN55024

• TCVN 7317

• V-2/2015.04

• V-3/2015.04

• CNS13438

• KN32

• KN35

• IEC 61000-6-1

• EN 61000-6-1

Additional Certifications for C9300L SKUs:

• QCVN 118:2018/BTTTT

• CISPR24/25

• CISPR 32 Class A

• VCCI-CISPR 32 Class A

• EN55035

Environmental Reduction of Hazardous Substances (ROHS) 5
